EOCR motor protectors (Used) in Pakistan BR1478
EOCR motor protectors (Used)
Application:
EOCR-SS electronic overload relay is suitable for AC 50/60Hz, voltage up to 600VAC and current up to 60A. The product conforms to IEC60947-1 standard.
Specification:
| Type | EOCR-SS | ||
|
Current range
|
05)0.5-5A(scale 6.5A) | ||
| 30)3-30A(scale 35A) | |||
| 60)5-60A(scale 70A) | |||
|
Rated voltage
|
600VAC,50/60Hz | ||
|
Operating setting
|
D-TIME | 0.2-30 seconds | |
| O-TIME | 0.2-10 seconds | ||
|
Accuracy
|
Current | ±10% | |
|
|
Time | ±15% of max.time set value | |
|
Time characteristics
|
Definite time | ||
|
Control voltage
|
220)Voltage free(90-260)VAC,50/60Hz 440)Voltage free(320-480)VAC,50/60Hz Other voltage optional. | ||
|
Current sensing
|
2 CTs | ||
|
Output contacts
|
Contacts
|
SPDT 3A/250AVC Resistive | |
|
Contacts
|
N Type
|
Normally energized :9598closed | |
|
R Type
|
Normally De-energized:95 98closed | ||
|
Reset
|
Manual or remote electrical by interrupting supply | ||
|
Environment
|
Temp.Run
|
Run
|
-20+70 deg.oC |
|
Store
|
-30+80 deg.oC | ||
| Humidity | 45-85% RH,non-condsing | ||
|
Insulation
|
Between casing and circuits:Over 10M?with DC 500V meager | ||
|
Dielectric strength
|
1)Between casing and circuits:AC 2000V,60Hz,1min | ||
| 2)Between contacts: AC 1000V,60Hz,1min | |||
| 3)Between circuits:AC 2000V,60Hz .1min | |||
