Pneumatic Air Regulator

Description

Pneumatic Air Regulator in pakistan BR1521

FBs-2A4RTD, FATEK PLC module

Introduction:

 FBs-2A4RTD is one of the Analog and Temperature
 mixed input modules of FATEK FBs series PLC.
 For analog input, it provides 2 channels A/D input
 with 12 or 14 bit effective resolution. Base on the
 different jumper settings it can measure the varieties
 of current or voltage signal. The reading value is
 represented by a 14-bit value no matter the effective
 the relation of input code and real input signal more
 intuitive.


Features:

 For temperature measure, It provides 4 channels of
 RTD temperature measurement input with 0.1 or 1 ?
 ? ? resolution. The scan rate for 0.1 resolution is 2
 second. This module provides a three-wire connection
 compensate the resistance introduced by the wiring.
 All the optional features of this module are software
 configurable, there are no hardware jumpers or
 switches for user to setup.
